MAD M6C08 IPE V3 brushless drone motor
MAD M6C08 IPE V3 brushless drone motor
The M6C08 IPE is designed to carry a payload of 1.5-3kg and supports 6S,8S,12S voltages.
Unique stator design, 24N28P configuration.
Passed the magnetic flux density simulation test, ensuring the motor in lower energy consumption.
| Specification | |||||||||
| Motor Model | MAD M6C08 IPE V3.0 | Number of pole pairs | 14 | ||||||
| Stator | Anticorrosive | Varnished wire Degree | 180°C | ||||||
| Motor Size | D:72 × 31.4 mm | Magnet Degree | 150°C | ||||||
| Degree of Protection | IP45 | Cable Length | 150 mm 16# Awg(Black) silicone | ||||||
| Centrifugal Heat Dissipation | YES | Rotor Balance | ≤5 mg | ||||||
| Propeller Mounting Holes | D:12 M3×4,D:18 M3×4,D:22 M3×4 | Motor Balance | ≤10 mg | ||||||
| Shaft Diameter | IN: 6 mm | Motor Mounting Holes | D:25 M3×4 | ||||||
| Bearing | EZO 696ZZ*2 | Disruptive test | 500 V | ||||||
